GRADES / FEATURES

Grade	Chemical compositions (%)			Physical performance	Applications
	WC	Cu+Zn+Sn	Co
ET-Cu-30	64-67	30±2	3.8-4.2	Hardness: >160HB TRS: >690MPa	Down hole tools Plungers, Shafts Agricultural/mining equipment Vlaves, Turbine Blades, Tool joints Extruder barrels and screws
ET-Cu-40	53-56	40±2	4.6-4.8
ET-Cu-45	48-52	45±2	4.2-4.5
ET-Cu-50	44-48	50±2	3.8-4.2

Item	Carbide particle size		Apperance	Available width (mm)	Available length (mm)
	(mm)	(inch)
1	1.6-3.2	1/8-1/16	Bare or with fluxed-coating	(20-22) (18-20) (10-12)	280-450
2	3.2-4.8	3/16-1/8
3	4.8-6.35	1/4-3/16
4	6.35-8.0	5/16-1/4
5	8.0-9.5	1/2-3/8
6	9.5-11.0	3/8-5/16

Please contact us for sizes which don't be mentioned in the above chart.
